• Veratron VMH Flex NMEA2000 Digitalanzeige für Bootstanks und Batterieüberwachung, 52 mm B00186401
1 2

VMH Flex NMEA2000 Gauge

VMH Flex NMEA2000 Gauge

B00186401

CHF 149.20
CHF 149.20
Sale Sold out
Taxes included. Shipping calculated at checkout.
Smart data converter and marine gauge for your vessel
The space-saving 52mm VMH Flex instrument reads both analog sensors and CAN networks seamlessly. It acts as an all-in-one converter, pushing your analog input data straight to the NMEA 2000 network.
  • IBS Battery Monitoring: Built-in LIN 2.0 interface allows direct access to key diagnostics from your Intelligent Battery Sensor.
  • Dual Tank Inputs: Features two resistive analog inputs calibrated for fuel, fresh water, or waste water tank senders.
  • Contactless Setup: Configure your marine display effortlessly with a simple touch using embedded NFC technology and a smartphone app.



Capable of reading 2x resistive analog inputs and CAN networks, the VMH Flex is further empowered by the LIN connectivity to get all the information from your battery thanks to the Intelligent Battery Sensor.



Manual

Specifications

  • Input supply voltage : 8-32 VDC
  • Nominal voltage : 12V|24V
  • Consumption : 50mA
  • Liquid type : Fuel|Fresh water|Waste water
  • Connectivity : NMEA2000|NFC
  • LIN inputs : 1x
  • Data transfer/conversion : Analogue to NMEA2000
  • Analogue input type : Resistive (Ω)|LIN Bus
  • Resistive signal inputs (Ω) : 2x
  • Signal resistance range : 0-180Ω|3-180Ω|10-184Ω|0-90Ω|90-4Ω|240-33Ω|240-33.5Ω|287.4-22.7Ω|322.8-18.6Ω|0-400Ω|2k Ω
  • Temperature range : 40-120°C/105-250°F|50-150°C/120-300°F|+50°C/+120°F|120°C/250°F|150°C/300°F|250°F/120°C|900°C/1650°F|100-900°C
  • Angle range : -40°/+40°|-45°/+45°
  • RPM range : 3000rpm|4000rpm|5000rpm|6000rpm|7000rpm|8000rpm
  • Pressure range : 2BAR/30PSI|5BAR/80PSI|10BAR/150PSI|25BAR/350PSI|30BAR/435PSI|150PSI/10BAR|400PSI/25BAR
  • Connector type : Micro-C (NMEA2000)|Molex MX150
  • Diameter : 52mm

Package content

  • 1x B00186401 VMH Flex– NMEA 2000
  • 1x A2C5205947101 52 mm spinlock nut
  • 1x A2C53194838 Rubber sealing gasket
  • 1x B001818 wiring harness
  • 1x safety instructions
