OL 43 TFT Display
OL 43 TFT Display
SKU:B00126101
Regular price
CHF 527.98
Regular price
Sale price
CHF 527.98
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
Exceptional clarity and multi-data control for helm stations
The multi-functional OL43 marine display delivers brilliant helm monitoring in demanding environments. Featuring an optically bonded 4.3-inch IPS-TFT anti-glare screen with premium mineral glass, it guarantees crisp visibility under direct sunlight.
The multi-functional OL43 marine display delivers brilliant helm monitoring in demanding environments. Featuring an optically bonded 4.3-inch IPS-TFT anti-glare screen with premium mineral glass, it guarantees crisp visibility under direct sunlight.
- Seamless Network Integration: Fully compatible with NMEA 2000®, SAE J1939 CAN protocols.
- Direct Analog Inputs: Features 1x frequency input (for engine RPM/tachometer), 2x resistive ports, and 1x voltage channel.
- EasyLink Expansion Path: Supports daisy-chaining up to 16 EasyLink satellite instruments for a multi-gauge cluster setup.
- Alarm Integration: Built-in 1x alarm output interface to trigger external buzzers or failure lamps immediately.
- Swiss Delivery Perks: Dispatched swiftly from our domestic warehouse with fair CHF pricing and zero import hassle.
Specifications
Specifications
- Input supply voltage : 9-32 V DC
- Nominal voltage : 12V|24V
- Consumption : 300mA @ 12 VDC
- Display size : 4.3"
- Connectivity : NMEA2000|J1939|EasyLink|Ethernet
- NMEA2000 inputs : Yes
- NMEA2000 outputs : Yes
- J1939 input : 1x
- EasyLink : 1x
- Data transfer/conversion : J1939 to NMEA2000|Analogue to NMEA2000
- Analogue input type : Voltage (V)|Resistive (Ω)|Frequency (Hz)
- Resistive signal inputs (Ω) : 2x
- Voltage signal inputs (V) : 1x
- Frequency signal inputs (Hz) : 1x
- Alarm outputs : 1x
- Connector type : Micro-C (NMEA2000)|Molex MX150|Ethernet M12-4poles
- Color : Black
