OceanLink Tachometer with LCD Gauge 85mm

SKU:A2C1065660001

CHF 238.00

Sale Sold out

Taxes included. Shipping calculated at checkout.

High-performance master tachometer and digital network hub
The OceanLink 85mm master tachometer automatically processes and displays your vital propulsion diagnostics. It converts your analog input data as well as the J1939 CAN bus signals fully automatically and feeds them directly into the NMEA 2000 network.

Smart Gauge Network: Functions as a digital bridge, broadcasting vital stats to up to 16 satellite displays (52mm) via EasyLink.
Hybrid Sensor Wiring: Features 2x resistive signal inputs (Ω) and 1x frequency input (Hz) for direct connection to legacy engine senders.
Advanced Network Paths: Equipped with 1x J1939 CAN input path and an industry-standard Micro-C NMEA 2000 interface.
Dial Options: Available in sleek black or classic white dial faces with scale ranges up to 3000, 5000, or 7000 RPM.

Manual

Specifications

Input supply voltage : 9-32 V DC
Nominal voltage : 12V|24V
Consumption : < 150 mA
Connectivity : NMEA2000|EasyLink|J1939
NMEA2000 inputs : Yes
NMEA2000 outputs : Yes
J1939 input : 1x
EasyLink : 1x
Analogue input type : Resistive (Ω)|Frequency (Hz)
Resistive signal inputs (Ω) : 2x
Frequency signal inputs (Hz) : 1x
Alarm outputs : 1x
RPM range : 3000rpm|5000rpm|7000rpm
Connector type : Micro-C (NMEA2000)|AMP superseal plug
Color : White|Black
Diameter : 85mm

Package content

1x Tachometer gauge
1x Bezel
1x Rubber seal
1x Mounting spinlock
1x Connection cable

Color Black White

RPM 3000rpm 5000rpm 7000rpm
