OceanLink Professional Rudder Angle Indicator Gauge 85mm
OceanLink Professional Rudder Angle Indicator Gauge 85mm
SKU:B00067401
Regular price
CHF 238.00
Regular price
Sale price
CHF 238.00
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
Commercial-grade rudder angle tracking and NMEA 0183 hub
The OceanLink Professional rudder indicator is purpose-built to deliver ultimate telemetry logging in heavy-duty commercial marine environments. It converts your analog input data fully automatically and feeds it directly into the NMEA 0183 network. Backed by its built-in transceiver, it shares telemetry smoothly with multiple daisy-chained gauges.
The OceanLink Professional rudder indicator is purpose-built to deliver ultimate telemetry logging in heavy-duty commercial marine environments. It converts your analog input data fully automatically and feeds it directly into the NMEA 0183 network. Backed by its built-in transceiver, it shares telemetry smoothly with multiple daisy-chained gauges.
- Hybrid Sensor Wiring: Equipped with 1x resistive signal input (0–180 Ω) and 1x voltage signal input (0–5 V) to support standard analog rudder senders.
- Digital Bus Channels: Features a reliable layout with 2x digital NMEA 0183 inputs and 2x NMEA 0183 outputs.
- Crisp Tracking Scale: The clean analog needle maps steering movements across a dedicated -45° to +45° angle range flawlessly.
- Infrared Calibration: Built with an embedded Infrared (IR) push-button system for wireless, effortless fine-tuning of the pre-set tracking profile.
- Marine Power Supply: Safe implementation for 12V and 24V yacht electrical grids (8-32 V DC) with a low maximum current draw of 100 mA.
Specifications
Specifications
- Input supply voltage : 8-32 V DC
- Nominal voltage : 12V|24V
- Consumption : max. 100mA
- Connectivity : NMEA0183
- NMEA0183 inputs : 2x
- NMEA0183 outputs : 2x
- Analogue input type : Resistive (Ω)|Voltage (V)
- Resistive signal inputs (Ω) : 1x
- Voltage signal inputs (V) : 1x
- Signal resistance range : 0-180Ω
- Signal voltage range : 0-5V
- Angle range : -45°/+45°
- Color : Black
- Diameter : 85mm
Package content
Package content
- 1x Rudder Angle gauge (B000674)
- 1x Wire harness
- 1x Mouting spinlock
- 1x Safety instructions
